Lvds Cms Software Loop Frameless Open Frame LCD Display Digital Signage
Lvds EDP Cms Software Loop Frameless Open Frame Lcd Screen Lcd Digital Signage Display Six-core RK3399 Android decoder drives all in one board
Overview:
Intelligent industrial all in one board, using Rockchip RK3399 six-core chip program, support Google Android7.1 or higher system. Powerful computing power. Support H.265 4K video playback. Rich interface and enhanced power management circuit. Suitable for intelligent remote network control: industrial, medical, large advertising, educational video terminals and other equipment.
Application Of LCD Digital Signage
Specification:
| System | CPU | RK3399 dual core Cortex-A72+quad core Cortex-A53,GPU ARM Mali-T860MP4 | |||||||||||||
| RAM | 4GB | ||||||||||||||
| Internal memory | 16/32/64GB (optional) | ||||||||||||||
| Operation system | Android 8.1 (optional) | ||||||||||||||
| Touch screen | 10 point capacitive touch(optional) | ||||||||||||||
| Display | Panel | 10.1" | |||||||||||||
| Resolution | 1200*1920 | ||||||||||||||
| Contrast ratio | 1000:1 | ||||||||||||||
| Luminance | 300cd/㎡ | ||||||||||||||
| Aspect Ratio | 16:10 | ||||||||||||||
| Network | WiFi | 802.11b/g/n | |||||||||||||
| Buletooth | Bluetooth 4.0 | ||||||||||||||
| Ethernet | 10M/100M/1000M Ethernet | ||||||||||||||
| Interface | USB interface | Support USB 2.0 , USB3.0 | |||||||||||||
| Micro USB | USB OTG*1 | ||||||||||||||
| DC | DC power 12V input | ||||||||||||||
| Card slot | SD card (Maximum support for 32G) | ||||||||||||||
| HD | Support HD output | ||||||||||||||
| RJ45 | Ethernet port | ||||||||||||||
| speaker | 2W * 8Ω * 2 | ||||||||||||||
| Earphone | 3.5mm earphone | ||||||||||||||
| Key | Key | Power V+ V- | |||||||||||||
| Media play | Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC1,VP8,RV etc.,support up to 3840x2160 | |||||||||||||
| Audio format | MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP etc. | ||||||||||||||
| Text processing | EPUB, WORD, EXCEL, POWERPOINT, PDF, | ||||||||||||||
| E-book | PDF,TXT,CHM,DOC,EXCEL,EPUB,RTF,FB2 | ||||||||||||||
| Photo | JPG,BMP,PNG | ||||||||||||||
system management | APK installation | APK installation | |||||||||||||
| Root permissions | Original ecological Android system, open root permissions, customizable development | ||||||||||||||
| Remote control | Real-time remote monitoring, system crash self recovery, 7*24 hours unattended | ||||||||||||||
| OTA upgrade | Support OTA remote upgrades | ||||||||||||||
| Camera | Pre 500W (default none , optional) | ||||||||||||||
| Language | Multi-language | ||||||||||||||
1) Q: Is SUNCHIP a factory or simply a trading company? FAQ
A: We are a TRUE OEM/ODM factory. Please read our COMPANY PROFILE, for more information on this issue.
2) Q: What payment methods are available to me?
A: We accept most of the payment methods: accept VISA, Pay Later,T/T,Western Union,Paypal and Cash.
3) Q: How long is the warranty time?
A: 1 Year.
4) Q: What are the shipment terms and delivery times of your company?
A: Delivery / production time is directly affected by the size of the order. Also depending in which season you are shipping.
5) Q: Do you give any discounts ?
A: Prices are directly affected by the quantity. We have many ways to help our partners when starting the sample processes. Make sure to ask our sales on how we can make you save some charges.
6) Q: I would like to add my company logo on your products, is this possible?
A: SURE.We customize on a regular basis products for many large retaillers and brands. If your order is at the below 10 units, we can consider this as a SAMPLE order, some fees might apply for the logo prints.
